Heavy-Duty 12" (305mm)
Double-Bevel Compound Miter Saw
Features
Double-Bevel Compound Miter Saw
Features
- 15.0 Amp, 4,000 rpm motor provides extended power and durability
- Stainless steel detent plate with 11 positive stops delivers repeatable accuracy and
worksite durability - Tall sliding fence supports crown molding up to 6-5/8" and easily slides out of the way for
bevel cuts - Gearbox and belt-drive design aid in delivering vertical capacity up to 6" base and 6-5/8"
crown molding - Double-bevel with positive bevel stops at crown molding settings, 0°, and 45° left and
right - allows user to flip the saw not the material - 0-50° (left and right) miter capacity for greater versatility cutting angles
- Quick bevel overrides provide capacity to bevel up to 48° both left and right to
accommodate out of square corners - Lightweight (44 lbs.), head lock-down pin, and built-in carrying handle increases portability
- Ideal for use with the DW723 miter saw stand
- Amps 15.0 Amps No Load Speed 4,000 rpm
- Blade Diameter 12 " Arbor Size 5/8" or 1 "
- Vertical Capacity: Baseboard Against Fence 6 "
- Vertical Capacity: Crown Molding Vertically Nested 6-5/8 "
- Horizontal Capacity: Baseboard Lying Flat 8 "
- Horizontal Capacity: Crown Molding Lying Flat 6-1/2 "
- 45° Bevel Cut Capacity (dimensional lumber) 2" x 8" left & right
- 90° Cross-Cut Capacity (dimensional lumber) 4" x 6 "
- 90° Cross-Cut Capacity (Max Width) 2" x 8" dimensional lumber
- 45° Miter Cut Capacity (Max Height) 4" x 4" dimensional lumber
- 45° Miter Cut Capacity (Max Width) 2" x 6" dimensional lumber
- Tool Weight 44 lbs Shipping Weight 49 lbs
- carbide blade dust bag
- blade wrench
$275.00
| Available at Hilltop Tool Rental |
| Miter Saws |
