Light Towers
Terex
Model RL 4000
28 ft (8.5 m) extended tower height.
Four 1,000 watt metal halide lights.
Cast aluminum lamp fixtures with tempered glass lenses.
"Tool-less" Quick Aim™ system features a rotational wheel and spring-
latch engagement point for both horizontal and vertical adjustment of
each lamp fixture.
Genie's patent-pending tilt-actuating system provides the ability to
vertically aim all four lamp fixtures from ground level.
Dual tower rotation handles and innovative handle-activated locking
mechanism to quickly lock tower in desired position.
UHMW plastic slide pads used throughout the entire mast assembly
provide long life and high level of corrosion resistance.
Patented fold-down outrigger system includes dual deployment positions
allowing easy setup on uneven surfaces.
Front panels are covered with an "ultra tough" polyurethane coating to
prevent rust and corrosion.
Impact-resistant foam core polyethylene plastic fenders will not rust.
Display panel is illuminated for operator convenience.
Controls are located behind a separate panel for easy access.
Field-proven cable routing system provides one of the cleanest and best-
protected power cable routing systems in the industry.
Features continuous run-time rating of 100 hours between fueling.
Forklift pockets and a crane attachment point provide easy transport on
and off delivery vehicles.
Specifications may change due to continuous product development.
Model RL 4000
28 ft (8.5 m) extended tower height.
Four 1,000 watt metal halide lights.
Cast aluminum lamp fixtures with tempered glass lenses.
"Tool-less" Quick Aim™ system features a rotational wheel and spring-
latch engagement point for both horizontal and vertical adjustment of
each lamp fixture.
Genie's patent-pending tilt-actuating system provides the ability to
vertically aim all four lamp fixtures from ground level.
Dual tower rotation handles and innovative handle-activated locking
mechanism to quickly lock tower in desired position.
UHMW plastic slide pads used throughout the entire mast assembly
provide long life and high level of corrosion resistance.
Patented fold-down outrigger system includes dual deployment positions
allowing easy setup on uneven surfaces.
Front panels are covered with an "ultra tough" polyurethane coating to
prevent rust and corrosion.
Impact-resistant foam core polyethylene plastic fenders will not rust.
Display panel is illuminated for operator convenience.
Controls are located behind a separate panel for easy access.
Field-proven cable routing system provides one of the cleanest and best-
protected power cable routing systems in the industry.
Features continuous run-time rating of 100 hours between fueling.
Forklift pockets and a crane attachment point provide easy transport on
and off delivery vehicles.
Specifications may change due to continuous product development.
| $7,775.00 |
Terex
Model AL5000
30 ft (9.1 m) extended height floodlight produces enough light to
illuminate 7-1/2 acres.
Self-braking, erecting and extending hand-operated winch with
self-lubricating aircraft cable is mounted inside the cabinet.
Storage racks for light fixtures are also inside cabinet.
Spring-loaded pin automatically locks galvanized 360° rotatable tower
in upright position.
Retractable power cord automatically recoils into protective rotatable
mast sleeve to prevent damage when raising, lowering and moving
tower.
Light fixtures plug into weatherproof receptacle box at top of tower
with UL and CSA-approved connectors.
Individual plug-in ballasts installed in galvanized steel boxes. Can
be replaced without disconnecting wiring terminals.
Control panel is inside, away from the elements. Houses main and
branch circuit breakers and hourmeter.
Galvanized outriggers with pre-set position stops insure quick and
proper spacing for safe operation in heavy winds.
Single point lifting eye and forklift pockets provided for easy loading
and unloading.
Specifications may change due to continuous product development.
Model AL5000
30 ft (9.1 m) extended height floodlight produces enough light to
illuminate 7-1/2 acres.
Self-braking, erecting and extending hand-operated winch with
self-lubricating aircraft cable is mounted inside the cabinet.
Storage racks for light fixtures are also inside cabinet.
Spring-loaded pin automatically locks galvanized 360° rotatable tower
in upright position.
Retractable power cord automatically recoils into protective rotatable
mast sleeve to prevent damage when raising, lowering and moving
tower.
Light fixtures plug into weatherproof receptacle box at top of tower
with UL and CSA-approved connectors.
Individual plug-in ballasts installed in galvanized steel boxes. Can
be replaced without disconnecting wiring terminals.
Control panel is inside, away from the elements. Houses main and
branch circuit breakers and hourmeter.
Galvanized outriggers with pre-set position stops insure quick and
proper spacing for safe operation in heavy winds.
Single point lifting eye and forklift pockets provided for easy loading
and unloading.
Specifications may change due to continuous product development.
| $18,999.00 |
| Available at Hilltop Tool Rental |
Chicago Pneumatic
The new CPLT is based on a successful existing concept that has
been used on the market for a long time. It includes a metallic
enclosure with wide service doors, an electrical cubicle for control
and protection, a math that will extend vertically up to 31 feet, and
that can be rotated 360º, stabilization legs and an on-road
undercarriage. The CPLT Light Tower is easy to operate and
extremely light and maneuverable, making it very simple to position
at the desired location for optimal work area lighting.
Standard Features
The new CPLT is based on a successful existing concept that has
been used on the market for a long time. It includes a metallic
enclosure with wide service doors, an electrical cubicle for control
and protection, a math that will extend vertically up to 31 feet, and
that can be rotated 360º, stabilization legs and an on-road
undercarriage. The CPLT Light Tower is easy to operate and
extremely light and maneuverable, making it very simple to position
at the desired location for optimal work area lighting.
Standard Features
- 4 metal halide lamps
- 1000 watts per lamp
- output 6kW
- Voltage 1220V
- Amperage 25 A @120V
- Receptacles 120V duplex
- Kohler diesel LDW1003
- Engine speed 1800 rpms
- Engine EPA rating tier 4
- Brush less generator
- Maximum power output 12.1 (9kW)
- Displacement 62.7 cu ft
- 30 gal fuel tank
- Fuel consumption 0.44 gal/hr
| $7,625.00 |
