Milwaukee Saws

FEATURES

Counter Balance
Gear Protection System
Milwaukee Electronic Speed Control 0-
3200 SPM

NCLUDES

Carrying Case
Two Super Sawzall Blades

10 Amp Model 6509-22 $129.95
11 Amp Model 6509-20 $169.95
10 Amp Quik-Lok 6537-22 $169.95

Super Sawzall

FEATURES

Cuts up to 4-3/4 in. x 4-3/4 in.
rectangular stock and 4-3/4 in. round
stock
6 amp, AC/DC
Two speeds: 250 and 350 sfpm
Uses standard 44-7/8 in. x 1/2 in. x .
020 in. band saw blades

SPECIFICATIONS

Voltage 120 AC/DC
Amps 6.0/5.0
No Load Speed 350/250 FPM
Capacity in Rectangular Stock 4-3/4
in. x 4-3/4 in.
Capacity in Round Stock 4-3/4 in.
Cord Type 8 ft. Fixed
Construction Type Grounded
Switch Type Trigger
Length 19-3/4 in.
Tool Weight 17.0 lbs.
Shipping Weight 22.0 lbs.

Model 6238 $339.95

Deep Cut Portable Band Saw

INCLUDES
14 Tooth Blade

SPECIFICATIONS

Voltage 120 AC/DC
Amps 15.0
Blade Size 7-1/4 in.
No Load Speed 5,800 RPM
Spindle 5/8 in.
Cord Type 9 ft. Fixed
Construction Type Double
Insulated
Metal/Wood Cutting Wood
Electric Brake No
Spindle Lock Yes
Soft Grip Handle Yes
Adjustable Handle Yes
Blade Position Right
Depth of Cut at 90° 2-7/16 in.
Depth of Cut at 45° 1-13/16 in.
Depth of Cut at 50° 1-11/16 in.
Length 13-3/4 in.
Tool Weight 10.4 lbs.
Shipping Weight 14.1 lbs.

INCLUDES

Circular Saw Blade
Hex Blade Wrench

Model 6390-20 $99.00

Tilt-Lok 7-1/4 in. Circular Saw

$287.99

SPECIFICATIONS

Voltage 120 AC
Stroke Length 1-1/4 in.
No Load Speed 0-3,200 SPM
Cord Type 8 ft. Quik-Lok
Construction Type Grounded
Switch Type Trigger
Dial Speed Control Yes
Keyless Blade Clamp Yes
Keyless Adj. Shoe Yes
Adjustable Handle No
Orbital Action No
Counter-Balance Yes
Impact Protection Yes
Length 17-7/8 in.
Tool Weight 8.8 lbs.
Shipping Weight 15.3 lbs.

FEATURES

New exclusive Tilt-Lok™ main
handle adjusts to the work or most
comfortable work position
10.4 pounds net weight - lightest 7-
1/4 inch, 3.25 maximum
horsepower saw reduces operator
fatigue, easier to handle
15 amp, 3.25 peak horsepower
motor - most powerful circle saw
cuts tough materials including
headers, microlams and wet lumber
with ease
Wide, clear sight line - superior
blade visibility from either side

Orbital Jig Saw

INCLUDES

Two 2.4 Amp-Hr.
18V Batteries
Universal Charger
Circular Saw Blade
Contractor Bag
Safety Glasses

18 Volt 6-1/2 in. Metal Cutting
Saw Kit

FEATURES

Cuts all types of metals such
as uni-strut, galvanized pipe
and metal studs
3,200 RPM and 2-1/8 in.
maximum depth of cut
Clear guard provides an
excellent line of sight for cutting
Electric brake for quick stops

SPECIFICATIONS

18 DC Voltage
6-1/2” Blade Size
Metal Cutting
2-1/8” Depth of Cut at 90°
3,200 RPM at No Load Speed
2 Batteries Included
2.4 Amp Hours
Electric Brake
Spindle Lock

Model 6320-20 $369.00

Panel Saw

FEATURES

Rigid all steel frame, square tubing is electrically welded to prevent warping or twisting
Comfortable horizontal handle for convenient on/off operation
20 amp commercial-grade paddle switch for durability and long life
Cutting accuracy to within 1/32 in. in either cross-cutting or ripping directions
Powerful 15 amp (3-1/4 max hp) Milwaukee motor (AC/DC)

Available at
Hilltop Tool Rental

Band Saw
Carrying Case
$50.95

SPECIFICATIONS

Voltage 120 AC
Amps 15.0
No Load Speed 5,800 RPM
Blade Size 8-1/4 in.
Spindle 5/8 in.
Cord Type 20 ft. Fixed
Construction Type Grounded
Switch Type Paddle
Trigger Lock On/Off
Capacity 1-3/4 in.
Height 70 in.
Length 60 in.
Tool Weight 170.0 lbs.
Shipping Weight 175.0 lbs.

INCLUDES
Circular Saw Blade 8-1/4 in. 40
Carbide Teeth (1 per pack)
Blade Wrench

Model 6480-20 1,469.00

FEATURES

LED light for improved sightline
Powerful 6.5 amp motor
Orbital action with 4 adjustment
levels and 1 in. stroke length for
faster cutting
Variable speed trigger - 0-3,000
SPM
Variable speed dial for repetitive
cuts
Quik-Lok™ blade change system
Keyless Shoe Adjustment - 45° in
both directions
Precision roller blade guide for
accurate cuts
Counter balanced for reduced
vibration
Tachometer feedback for constant
cutting speed
Cushion grip for superior gripping
and control

INCLUDES

Anti-Splintering Device
Plastic Shoe Cover
Carrying Case for Jig Saws
Two Blades
Dust Shield

Model 6268-21 $167.95

SPECIFICATIONS

Voltage 120 AC
Amps 6.5
Stroke Length 1 in.
No Load Speed 0-3,000 SPM
Blade Type T-Shank
Cord Type 12-2/3 ft. Fixed
Construction Type Double
Insulated
Switch Type Trigger
Trigger Lock On
Dial Speed Control Yes
Keyless Blade Clamp Yes
Orbital Action Yes
Length 9-1/2 in.
Tool Weight 6.4 lbs.
Shipping Weight 9.9 lbs.

Band Saw Blades Bi-metal, 44-7/8" available in 10,
14, 18, 24, 10/14, or 14/18 tooth.
$5.02 ea.
100 + $3.95 ea.

Body Grip Orbital Jig Saw

Features

Powerful 6.2 amp motor
Orbital action with 4 adjustment levels for
faster cutting
7 setting dial speed control 500-3000 SPM
Quik-Lok™ blade change system
Keyless 45° bevel adjustment
10 position dust blower and built-in dust
collection port for easy attachment to vacuum
Die cast aluminum shoe and all metal gear
case
Low position roller guide for blade stability and
precision cuts
Counter balanced for reduced vibration

Specifications

Voltage 120 AC
Amps 6.2
Stroke Length 1"
No Load SPM 500-3,000
QUIK-LOK™ blade change
Orbital Action Yes-4 Position
Tool-Free Blade
Tool Free Bevel
Handle Type Barrel

Model 6276-21 $167.95

Blade Type T-Shank
Cord Type 9-1/2 ft. Fixed
Double Insulated Construction
Switch Type Trigger
Trigger Lock On
Dial Speed Control Yes
Length 11-3/4"
Tool Weight 5.0 lbs
Shipping Weight 8.4 lbs
