Multiquip Generators and Welders
Model TLW-300SS
Performance Data
Prime Output KW (KVA): 10.5 Kw
Sound Level dB(A) - full load 23 feet: 65 dBA
Rated Voltage: 31.2
Current Range: 35-300 Amps
Duty Cycle: 100% to 280 Amps
Maximum Output - Amps: 300 Amps
Continuous Amps: 43.7 x 2 /43.7
Frequency / Phase: 50/60 Hz/Single Phase
Power Source
Displacement cu. in (cc): 719 cc
Fuel Consumption - full load - gph (lph): .7 gph
Engine Coolant Capacity - gal (liters): .55 gal
Fuel Tank Capacity - gal (liters): 9.5 gal
Engine Design: 4-cycle, water cooled, swirl chamber
Engine Model: D722
Engine HP; rpm: 19 HP
Oil Capacity - gal (liters): .83 Gal
Engine Make: Kubota
Starting System: Electric
No. Cylinders: 3
Voltage/Phase: 120/240 V
Rated Output: 87/44 amps of the generator
Performance Data
Prime Output KW (KVA): 10.5 Kw
Sound Level dB(A) - full load 23 feet: 65 dBA
Rated Voltage: 31.2
Current Range: 35-300 Amps
Duty Cycle: 100% to 280 Amps
Maximum Output - Amps: 300 Amps
Continuous Amps: 43.7 x 2 /43.7
Frequency / Phase: 50/60 Hz/Single Phase
Power Source
Displacement cu. in (cc): 719 cc
Fuel Consumption - full load - gph (lph): .7 gph
Engine Coolant Capacity - gal (liters): .55 gal
Fuel Tank Capacity - gal (liters): 9.5 gal
Engine Design: 4-cycle, water cooled, swirl chamber
Engine Model: D722
Engine HP; rpm: 19 HP
Oil Capacity - gal (liters): .83 Gal
Engine Make: Kubota
Starting System: Electric
No. Cylinders: 3
Voltage/Phase: 120/240 V
Rated Output: 87/44 amps of the generator
| Call for Pricing |
| Call for Pricing |
Model BLW-400SS
Performance Data
Prime Output KW (KVA): 14 KW
Sound Level dB(A) - full load 23 feet: 67.5
Rated Voltage: 34V Single, 27V Double
Current Range: 70-400 Amps (Single), 35-200 Amps (Double)
Duty Cycle: 100% @ 350 Amps
Maximum Output - Amps: 400 Amps (Single), 200 Amps (Double)
Continous Amps: 116/58
Frequency / Phase: 60 Hz Single Phase
One man operator 400 amps or 2 man at 200 amps each
Power Source
Displacement cu. in (cc): 1189 cc
Fuel Consumption - full load - gph (lph): 1.6 gph
Engine Coolant Capacity - gal (liters): 1.6 gal
Fuel Tank Capacity - gal (liters): 10.5 gal
Engine Design: 4-cycle, water cooled, direct injection
Engine Model: V1205
Engine HP; rpm: 31 HP, 3600 RPM
Oil Capacity - gal (liters): 1.3 Gal
Engine Make: Kubota
Starting System: Electric
No. Cylinders: 4
Voltage/Phase: 120/240 V
Rated Output: 116/58 amps
Performance Data
Prime Output KW (KVA): 14 KW
Sound Level dB(A) - full load 23 feet: 67.5
Rated Voltage: 34V Single, 27V Double
Current Range: 70-400 Amps (Single), 35-200 Amps (Double)
Duty Cycle: 100% @ 350 Amps
Maximum Output - Amps: 400 Amps (Single), 200 Amps (Double)
Continous Amps: 116/58
Frequency / Phase: 60 Hz Single Phase
One man operator 400 amps or 2 man at 200 amps each
Power Source
Displacement cu. in (cc): 1189 cc
Fuel Consumption - full load - gph (lph): 1.6 gph
Engine Coolant Capacity - gal (liters): 1.6 gal
Fuel Tank Capacity - gal (liters): 10.5 gal
Engine Design: 4-cycle, water cooled, direct injection
Engine Model: V1205
Engine HP; rpm: 31 HP, 3600 RPM
Oil Capacity - gal (liters): 1.3 Gal
Engine Make: Kubota
Starting System: Electric
No. Cylinders: 4
Voltage/Phase: 120/240 V
Rated Output: 116/58 amps
| Available at Hilltop Tool Rental |
