Generators
Heavy-Duty Gas-Powered Generators
Milwaukee's heavy-duty gas-powered generators are designed to deliver
reliable power, maximum durability, and unmatched performance to the
jobsite. The generators features a durable, 1-1/4" steel roll-cage frame,
rugged, 12" all-terrain non-flat tires, and an impact-resistant stainless
steel control panel which is recessed and reinforced by a solid steel frame
support. The control panel circuit breakers and panel switches are 100%
sealed and all receptacles are shielded by a UV and rain-resistant shield.
Finally, engine vibration is minimized with a heavy-duty, solid-steel engine
mount spreader bar with durable, rubber vibration mounts. In addition,
they features an automatic engine idle control which reduces fuel
consumption and noise during no-load periods. For convenient
transport, lifting and storage, they features a durable, quick-release
folding, handle and permanent, fold-away Lift-Hook.
Available at Hilltop Tool Rental
|
Model
|
4950-20
|
4960-24
|
4070-24
|
Price
|
$1,995.00
|
$2,495.00
|
$2,795.00
|
Rated AC Output
|
4,500 watts
|
5,500 watts
|
6,500 watts
|
Maximum AC Output
|
5,000 watts
|
6,000 watts
|
7,000 watts
|
Surge AC Output
|
6,700 watts
|
8,250 watts
|
9,750 watts
|
Rated AC Current (120v/240v)
|
38 amps / 19 amps
|
46 amps / 21 amps
|
54 amps / 27 amps
|
Maximum AC Current (120v/240v)
|
42 amps / 21 amps
|
50amps / 23 amps
|
58 amps / 29 amps
|
Alterntor Type
|
Brushed
|
Brushed
|
Brushed
|
Max. HP
|
9.0 HP
|
11.0 HP
|
13.0 HP
|
Noise Level
|
70 dBA
|
70 dBA
|
72 dBA
|
GFCI Reciptacles
|
20A/120V 3P Outlet (4) 20A/120V Twist-Lock (1) 30A/120V Twist-Lock (1) 20A/120-240V Twist-Lock (1)
|
20A/120V 3P Outlet (4) 20A/120V Twist-Lock (1) 30A/120V Twist-Lock (1) 30A/120-V Twist-Lock(1)
|
20A/120V 3P Outlet (4) 20A/120V Twist-Lock (1) 30A/120V Twist-Lock (1) 30A/120V Twist-Lock(1)
|
Circuit Protection
|
Branch Rated (UL 489 Approved)
|
Branch Rated (UL 489 Approved)
|
Branch Rated (UL 489 Approved)
|
Engine Brand
|
Vanguard OHV (#184532)
|
Honda OHV (GX340)
|
Honda OHV (GX390)
|
Starting System
|
Recoil
|
Recoil
|
Recoil
|
Fuel Tank Capacity
|
7.5 gallons
|
7.5 gallons
|
7.5 gallons
|
|
